Heat transformer also known as Type-II heat pump, medium grade heat is pumped to high grade heat. With a heat transformer, waste heat can be upgraded, virtually without the use of high temperature driving energy.
The input heat source i.e., Waste heat of a medium temperature is supplied to the evaporator and generator and useful heat of higher temperature is given off in the absorber. These heat transformers can achieve a delivery temperature up to 160ºC, typically with a lift of 50ºC.
Operating Range
Capacities: 0.5 to 15.0 MW
Hot water temperature: Up to 160ºC (320ºF)
Output : Hot water up to 170ºC
Medium Grade Heat source: Steam, hot water & liquid/gas fuels (individually or in combination)
COP: 0.4 – 0.47
Steam pressure  up to 6.0 bar.g

PRODUCT FEATURES
Thermax is a leading manufacturer of vapour absorption cooling systems. Thermax vapour absorption chillers are extensively used worldwide for industrial refrigeration, air conditioning, process cooling and heating. Our absorption cooling and heating business offers an extensive range of chillers that use waste steam, hot water, thermic fluid, exhaust gases and other fuels.
True to our organistion’s vision, our technology uses natural green refrigerant i.e. ‘water’. By avoiding the use of harmful refrigerants like CFCs, we make our eco-friendly absorption systems a natural choice for green energy planners.
